LED inground light is widely used, because it is buried in the ground for lighting and so named buried lamp, electric voltage: 12V -- 220V power rate: 1-36W protection grade: IP6.5 control mode: internal control, external control, DMX512 control can be; The light source has two kinds of ordinary light source and LED light source, high power LED light source and low power LED light source are generally monochrome, the lamp body is generally round, square, rectangular, arc, LED light source has seven colors, the color is gorgeous. LED underground lights are widely used in lighting decoration in squares, restaurants, private villas, gardens, meeting rooms, exhibition halls, community environment beautification, stage bars, shopping malls, parking sculptures, tourist attractions and other places.
The installation steps of LED underground light is as follows.
1. Preparation before installation
1) Prepare spare parts and necessary tools;
2) The power supply must be cut off before installation;
3) Dig the embedded hole according to the outer diameter of the embedded part first, and then fix it with concrete;
4) The diameter of the main line must be greater than the diameter of the lamp;
2. Installation process
1) After the embedded parts are fixed, connect the input wire of the buried lamp with the external wire (the phase wire, neutral wire and ground wire should be connected and waterproof).
2) Fix the lamp body assembly and the embedded parts with screws.
3) The surface cover plate is firmly fixed on the lamp body assembly with screws.
4) After confirming the above operation is correct, switch on the power supply.
